Syringe Pump con testata separabile dal corpo dello strumento, ideale per prove con controllo remoto in ambienti che richiedono la massima sicurezza.

Modello ad un canale, in grado di ospitare una siringa nel range di capacità 5÷1000 µl, con una velocità impostabile tra 0,61÷95,25 mm/min ed un range di portata dipendente dalla siringa tra 0,052÷1,558 ml/min.

Products introduction

TFD01-01 Syringe pump is one channel multi mode micro syringe pump. Its controller and the execution unit for fission structure, execution unit is equipped with a mounting bracket, convenient use cooperatively with microscopic operating equipment, stereotaxic instrument and other fixtures , execution unit can be used with 5 ul - 1000 ul microliter syringe, high precision control, suitable for all kinds of biological experiments.High resolution color LCD, touch screen is convenient fast set parameters, multiple light is clear and confirmed its working status, support infusion withdrawal and other five working modes.Built-in RS - 485 communication, support the Modbus protocol, full metal shell, wide range power input, adapt to various occasions.

Function and Features.

• Can assemble a LF - Toutch - GUI software system, stable and reliable running, powerful function.Image of the animation and icon is displayed, and colorful interface, convenient touch screen operation, the commonly used function keys, make the device more easy to use;
• A variety of work mode choice;
• Fission design, easy to installation and fixation.
• Color touch screen LCD, convenient and quick operation;
• Support screen lock, key mute operation;
• With lights buttons, clearly working state;
• Support a variety of standard syringe, customizable syringe;
• High precision control;
• RS485 communication, support the Modbus protocol;
• External signal control start-stop and direction;
• A wide range of power input;
• Full metal shell

The parameters

• The software system: LF - Toutch - GUI (standard);LF - LabComSoft computer control software (optional)
• Syringe specification: 5 ul - 1000 ul;
• Work mode: infusion, withdrawal, infusion/withdrawal, withdrawal/infusion, continuous mode;
• Channel number: 1;
• Max stroke Range: 70 mm;
• Stroke resolution: 0.198 um/ustep;
• Linear velocity range: 0.635 um/min to 95.25 um/min;
• The linear velocity regulating resolution: 0.635 um/min;
• Linear travel accuracy: error < plus or minus 0.5% (30%) stroke > maximum stroke;
• Linear thrust, maximum rated: > 20 n.
• Thrust adjustment: 1-100% arbitrary adjustable.
• Syringe selection: built-in syringe manufacturers,choose using model; Or custom syringe, direct input syringe diameter;
• Flow correction: through the calibration procedure to obtain more accurate fluid volume;
• Display: 4.3 -inch color LCD, 480 * 272 resolution, color 65 k;With screen display and transfusion volume, quantity of liquid, flow rate, direction, syringe specification, etc.;Animation display operation status;
• Operation mode: touch screen + commonly used functions button;
• Power-off memory: keeping previous parameters;
• Other features: pause and stop;The sound tip;The lock parameters;Fast forward and retreat quickly;
• Indicator, state signal output: 1 road stop state, 1 road for direction;
• Control signal input: 1 way down along the priming start, 1 way down along the trigger to stop;
• Communication interface: RS485, MODBUS protocol;
• Power supply: AC90V - 264V;
• Power consuption:20W
• Working temperature: 5 to 40 ℃;
• Work environment relative humidity: < 80% RH;
• Controller dimension size: 245 * 195 * 133 mm
• Drive dimension:70×44×194mm
• Weight:3.2kg
