Main Features

• Touch screen with 10.4”color LED display,resolution 1024*600
• Large Intelligent operation interface,easy connect to PC
• Flexible Plate layout with Blanks, Standards, Samples, Reference, QC in one screen
• Comprehensive qualitative and quantitative data-evaluation functions with cut-offs, curve-fits and transformation formulas
• More than 20 different report formats
• Auto Lamp adjustment and auto calibration
• Support keyboard and mouse with USB interfaces
• Stable memory stores up to twenty million test data,500 test projects

Technical Specifications

• Microplate types: 96/ 48 -well plate
• Photodetector: Silicon Photodiode
• Light source: 8v/50w Controlled tungsten halogen lamp
• Wavelength range: 400nm~850nm
• Standard filters: 405,450,492,630nm & 4 optional
• Reading range: 0.000~4.000A
• Resolution: 0.001A
• Accuracy: ±0.008A
• Reproducibility: =0.2%
• Stability:±0.003A
• Reading Speed : Single Wavelength=3s ;Double Wavelength=6s
• Shaking: Linear Shaking , 3 speeds
• Printer :Built-in Thermal Printer,optional external printer
• Interface connections: DVI,VGA,NETWORK INTERFACE,USB,AUDIO INTERFACE, RS-232
• Power supply: 100~240V, 50~60Hz
• Dimensions: 460(L)×350(W)×197(H)mm
• Net weight: 8kg
